View Images

Orig. Price: $80.00 Sale Price: $44.99 Availability: This product is unavailable for ordering at this time. please call 989-644-2695 for availability of Reconditioned Units. Prod. Code: MM-0280150364

Cross reference #

BorgWarner                    # 57009

G.B. Remanufacturing  # 832-12101

 OEM                                #  4275312

Applications:

If you plan on using the Bosch 0280150364 as a replacement for the 0280150158 please refer to the following information below:

UPDATE: the 0280-150-364 injector test results are in! In summary the 0280-150-364 injectors are perfect replacements for the stock Carrera 0280-150-158 injectors! Read on and see for yourself.

If you recall back about a year ago I was going to test 0280-150-364 bosch injectors as replacements for the stock 0280-150-158 injectors in the Carrera 3.2L. See post #117 for details.

Well, I finally have my AirFuelRatio tuned to about 13.0AFR across the entire RPM range (1000-6800RPMs) while in a 2nd Gear WideOpenThrottle street run. So now I have a baseline to compare the 360 injectors to, here is what the AFR looks like with the stock 158 Injectors:



As you can see above I have spent many hours tunning my AFR to about 13.0AFR across the RPM range at WOT. Took me the better part of a year to learn how to burn chips and tune these cars.

Then once tuned with the 158 injectors I simply removed them and installed the 364 test injectors, the results where nice surprise! I did not even re-set the CO base mixture just dropped them and re-ran the test. Here are the results for the 0280-150-364 injectors:



As you can see the 364 injectors ran about 13.1AFR across the RPM range. I conclude that these injectors are great alternative injectors to the 158 stock ones.

I can tell they run slightly leaner than the stock ones but not by much, next I will set the base CO and richen up the idle mixture back to spec of 14.2AFR, right now the idle AFR is about 14.5AFR a tad lean but can be easily brought down by simple adjustment of the CO screw on the AFM.

So there you have the results, took a year but they are in!
